About our models:
Turbine T-Rex 700 Helicopter (Esprit Model Custom Project):
Here is David's latest helicopter project. He is installing one of the new Wren 44 turbines into a T-Rex 700 Nitro airframe. With the listed 6.8 horsepower output, this helicopter is sure to be fun. So far the frame modifications are almost complete and the fan shroud is just about fitted.
The T-Rex 700/Wren is just about ready to fly. All of the building is finally done. Everything turned out nicely. Only a bit of radio set-up is left to do. We have already started the engine and it works fabulously!! Everyone should have their own jet engine. A larger fuel tank will probably be in its future though. The current flying (wet) weight is 5.96Kg (13.15 lbs).
Watch for more photos!!



EM eBandit EDF120 (Esprit Model Custom Paint):
The eBandit in an exquisite, all composite, state-of-the-art design that have revolutionized jet models. This time honored design has been tweaked just a bit for even better flight characteristics and customer convenience. The eBandit uses the large wing platform of the balsa Bandit with its "Vess Designed" airfoil that includes wing tip wash-out for extra slow flight stability and even increased the flap area for easier grass-field take offs and safer landings.
Flying time: 6-6.5 minutes
Wingspan: 69" (1750mm)
Length: 73" (1855mm)
Weight: 16-18 lbs. (7265-8170g)
Power: StuMax SM110-45, Neu 1527/1.5Y, EM30c 4500mAh 12S Li-poly battery



EM Electra Jet EDF120 (Esprit Model Custom Paint):
BVM's Electra Jet "ARF" size, performance and the state-of-the-art design have revolutionized all electric jet models. All composite, custom painted airframe is strong and light. With the BVM Electric VioFan, it is flight worthy at speeds exceeding 200mph (320 km/h), but stable slow flight and easy landings are where the Electra Jet really shines.
Flying time: 6-6.5 minutes
Wingspan: 60" (1525mm)
Length: 67" (1700mm)
Weight: 14 lbs. (6355g)
Power: BVM EVF 5012, Neu 1524/2Y, EVO 30 FP6400 12S Li-poly battery


EM Spark Jet EDF100 (Esprit Model Custom Paint):
The Spark EDF is consequently designed as a very lightweight all-composite structure, with features similar to a world class F3A-Pattern plane. Lightest lay-ups, perfectly engineered aerodynamics and structural reinforcements only where they are needed; the Spark is perfectly suited for electric ducted fan flying (EDF).
After flying the Spark for more than an entire flying season, we came to the conclusion that it is one of the most sophisticated designs in our product range. With various power choices we achieved speeds well over 185 mph (300 km/h).
Flying time: 5-5.5 minutes
Wingspan: 48" (1220mm)
Length: 63" (1600mm)
Weight: 10 lbs. (4540g)
Power: TJ100, Neu 1515/3D, TP3850 10S Li-poly battery


BVM MiG-15:
The Mikoyan-Gurevich MiG-15 (NATO reporting name Fagot) was a jet fighter developed for the USSR by Artem Mikoyan and Mikhail Gurevich. The MiG-15 was one of the first successful swept-wing jet fighters, and it achieved fame in the skies over Korea, where early in the war, it outclassed all enemy fighters. This is super scale electric ducted fan conversion of MiG-15 jet from Bob Violet Models.
Flying time: 6-6.5 minutes
Wingspan: 68" (1725mm)
Length: 68" (1725mm)
Weight: 20.5 lbs. (9300g)
Power: TAM EDF TJ100, Neu 1518/1.5Y, EVO 30 FP6400 12S Li-poly battery




Flash Video:
BVM Electra Jet:
BVM's Electra Jet "ARF" size, performance and the state-of-the-art design have revolutionized all electric jet models. All composite, painted-in-the-mold airframe is strong and light. With the BVM Electric VioFan, it is flight worthy at speeds exceeding 200mph, but stable slow flight and easy landings are where the Electra Jet really shines.
Flying time: 6-6.5 minutes
Wingspan: 60" (1525mm)
Length: 67" (1700mm)
Weight: 14 lbs. (6355g)
Power: BVM EVF 4012, Neu 1521/2Y, EVO 30 FP6400 12S Li-poly battery



Stork E:
This is compact precision hollow molded sport electric sailplane. Fully made of gel-coated fiberglass and reinforced with Carbon Fiber. Very sleek high performance design, rock solid almost at any wind conditions. Average flying time is around 1-2 hours, depending on the weather.
With Hacker B50 9S w/6.7:1, Graupner 18x10 folding prop and TP4200 3S2P Li-Polymer battery I get around 20-25 climbs.
Wingspan: 118.5"
Length: 55"
Weight: 77 oz.

Piper PA-18 Super Cub (Clipped Wing):
One of classic models every one of us must have. The Cub is also our biggest and heavies plane so far we have converted to electric. This model is pure joy to fly, scale like performance, smooth as a silk.
AXI 5330/24, TP6000 10S3P Li-Poly battery pack and APC-E 21x14 propeller.
Flying time is around 20 minutes per charge.
Wingspan: 88"
Length: 72"
Weight: 16.5 lbs.

Aggressor:
This is one of best model airplanes I have ever flown.
Pure joy to fly, powerfull, precision and very easy to land.
At maident flight all it needed was one click with elevator and two clicks with aileron trim.
Hacker C50 14XL w/6.7:1 gearbox, TP6000 10S3P Li-Poly battery pack and APC-E 22x12 propeller. My flying time is around 20 minutes per charge.
Wingspan: 78.5"
Length: 78.5"
Weight: 10.5 lbs.


Cosmic Wind
Scale Racer fast, but not way too fast model. Jeti 45/3 brushless motor,
16 cells NiMH 3000 mAh battery pack, APC-E 11x7 propeller. Flying time
10-11 minutes full of aerobatics. Needs to be controlled all the time.
Not for beginners. The model is fiberglassed and painted.
Weight: 6 lbs.

Benji
Aerobatic, slim and fast model. I have been flying this model with Jeti
15/3 brushless motor, 8 cells NiMH 3000mAh battery pack, APC 7x7 propeller
almost for five months. Average flying time was around 9-12 minutes
of (for some people) very scary flying. Still very predictable and stable.
The model is fiberglassed and painted.
Wingspan: 43"
Length: 34"
Weight: 40oz.

Smart 40:
Classical 40-size ARF trainer. I bought it just for fun, but mainly
fly with electric model of the water and check my new fiberglass floats.
Jeti 45/3 brushless motor, 16 cells 3000 mAh battery pack with APC-E
11x7 propeller.
I can takeoff and land 15-20 times or just cruise for 10-12 minutes,
without fear of loosing the engine. Once when I almost flipped model
the engine went under water. Guess what? Nothing happened because is
electric. I restarted the motor and took off again. Since then I have
always loved flying of the water.
Wingspan: 61"
Length: 51"
Weight: 7 lbs.
Slow Poke:
My only classic IC model. Good, reliable OS MAX FS-40 Surpass engine.
The whole model has been highly modified with flaps, ailerons and inverted
motor. It’s covered and finished in Stits paint system. A very
nice flyer.
Wingspan: 50"
Length: 38.5"
Weight: 3.5 lbs.

Diablo Top FG:
One of the best planes that I have ever flown. Fully aerobatic, very stabile and predictable model. If you would like
to do a snap rolls straight up, this is way to go. I currently using Hacker B50 9XL w/5.2:1 gearbox, TP8000 6S4P Li-Poly
battery pack and APC-E 16x10 propeller. My flying time is around 25 minutes per one charge.
Wingspan: 65"
Length: 65.5"
Weight: 7 lbs.

Diablotin Super FG:
This is my favorite plane. Flies like a big parkflier. I would say this is the ultimate trainer. My best proven set up:
Hacker C50 10L w/6.7:1, TP8000 5S4P Li-Poly battery pack and APC-E 19x10 propeller. Flying time around 40 minutes per one charge.
Wingspan: 61"
Length: 65.5"
Weight: 4.5-6 lbs.

Senior Kadet:
This is my favorite model airplanes. This monster flies like a big parkflier. I would say this is the ultimate trainer,
specially with floats.
It really takes off the grass on the floats.
My best proven set up: AXI 4120/18, TP8000 5S4P Li-Poly battery pack and APC-E 14x10 propeller. Flying time around 25
minutes per one charge.
Wingspan: 80.5"
Length: 65"
Weight: 8.5 lbs.

"Piggy-Back" glider launch!!!:
Our Senior Kadet on floats with 111" Mystic.
It really takes off the grass on floats.
My best proven set up: AXI 4130/16, 16x10 prop, TP8000 6S4P
Up to 15 launches on 1 charge.
Watch them fly: Video 1.6MB



Lambada:
I love the shape of this model. It's fully aerobatic fun-fly type.
I can do 1/2 mile long knife edge flights.
Hacker C50 7XL w/6.7:1 gearbox, TP8000 6S4P Li-Poly battery pack and APC-E 18x8 propeller. My flying time is around 25 minutes per charge.
Wingspan: 66"
Length: 61"
Weight: 8.5 lbs.

"Good Time" with DHLG G-FORCE
Let me introduce myself.
I am "Max" (sugar glider) Zb's personal assistant.
"MAX" the inspector is checking firewall installation.
|
Is the cowl attached properly?
|
Yes, the prop is balanced just fine.
|
Time for afternoon nap, maybe a small snack.
|
"Good night guys" (it's cold, fortunately I have electric heated pillow)
|
Small snack tastes better "upside down".
|
...Check my new girlfriend.
Are you jealous?
|
Hmmmm.....they are perfekt.
My boss sells quality!!!
|
We are soooo.. cute!!!
|
Launch time....
|
|
|
