AXi 15 2814/20 Sailplane Outrunner Brushless Motor V3


Price: $105.00
In Stock: 4
Part: MAXI-2814-20v3-L
Back In Stock Notification
Made In Czech Republic
Jeti Care Services
Jeti Care Services
Jeti Fight Club
AXi 2814/20 Sailplane Outrunner Brushless Motor V2
AXi 2814/20 Sailplane Outrunner Brushless Motor V2
2814 Outrunner Series
2814/20
Kv (rpm/V) 840
Max Power (W) 375W
Max Amp (15sec) 30A
Max Efficiency 83%
Io (No load A) 0.7A
Rm (Resistance) 0.145Ohm
Shaft Diameter 5mm
Gearbox N/A
Motor Diameter 35mm
Motor Length 45mm
Motor Weight 106g
Built in Fan Yes
Max Rpm 20,000
Poles 14
Case Outrunner
ESC Timing 20-25 deg
ESC Switching Freq. 8kHz
Model type Model name Motor Controller Battery Prop
Sport FunCub 15e 2814/20 Jeti Advance 30 2100 3S Li-poly 11x5.5 APC-E
Aerobatic/3D 3DH Extra 300 2814/20 Jeti Advance 30 2700 3S Li-poly 12x6 APC-E
Sailplane 2m Meteor 2E 2814/20 Jeti Advance 30 2700 3S Li-poly 12.5x6 Folding



AXi 2814/20 Sailplane Outrunner Brushless Motor V2



Related Products:

Jeti Spin Pro 33 Brushless ESC with Telemetry
Price: $75.00    In Stock: 11
ratingratingratingratingrating
Jeti Spin Pro 33 Brushless ESC with Telemetry

Product Reviews:

(1 Rating, 1 Review) Average Rating:
ratingratingratingratingrating
ratingratingratingratingrating
Worth the investment.
Daniel Shoemaker (Denton, TX) 7/22/2016 9:12 AM
I put this 2814/20 in my Multiplex Heron and saved about 55-60 grams over the Neu and gearbox I had. Installation was simple, it eliminated the home made standoff I needed behind the motor mount due to the protruding gearbox. It pulls about the same amps (28a in climb) with a 13 x 8 folder, and climbs only very slightly slower.
