Esprit Elite 200cc E105/30-105 3D HD Outrunner Brushless Motor w/Telemetry


Price: $825.00
In Stock: 1
Part: MAR-E10530-105
Back In Stock Notification
Made In Czech Republic
Jeti Care Services
Jeti Care Services
Jeti Fight Club
Marten 200cc E105/30-105 3D HD Outrunner Brushless Motor w/Telemetry
E105/30 HD Series
Elite 200cc 105 3D
Kv (rpm/V) 105
Max Power (W) 9000W
Max Amp (15sec) 185A
Max Efficiency 95%
Io (No load A) 4.5A
Rm (Resistance) 0.0248Ohm
Shaft Diameter 10mm
Gearbox N/A
Motor Diameter 119mm
Motor Length 93.5mm
Motor Weight 2400g
Built in Fan Yes
Max Rpm 7,000
Poles/Stator 28/24
Case Outrunner
ESC Timing 20 deg
ESC Switching Freq. 8kHz

Hardened steel shaft, 30mm oversize bearing, bolt-on prop adapter, integrated cooling fan and pre-installed Jeti telemetry sensors represent the highest level of quality.

Model type Motor Controller Battery Prop Power/A/RPM
Scale/Sport E105/30-105 Jeti Spin Pro 200 7000 14S Li-poly 32x12 Fiala 5000W/95A/4450
Scale 66 lbs./30kg E105/30-105 Jeti Spin Pro 200 7000 15S Li-poly 32x12 Fiala 6100W/110A/4650
Scale 77 lbs./35kg E105/30-105 Jeti Spin Pro 200 7000 14S Li-poly 36x10 Fiala 0000W/0A/0000
Aerobatic 150-200cc E105/30-105 Jeti Spin Pro 300 7000 14S Li-poly 36x14 Fiala 0000W/0A/0000





Marten 200cc E105/30-105 3D HD Outrunner Brushless Motor w/Telemetry

Marten 200cc E105/30-105 3D HD Outrunner Brushless Motor w/Telemetry
